Product Introduction
Rod Mill, is a grinding machine similar to a ball mill. The obvious difference between the two is the grinding medium. Rod mill is named after the medium is a steel rod. The latter's grinding medium is undoubtedly a steel ball. Both of them can be used for grinding various metal ore and non-metal ore. In some case, rod mill is also called rod type sand making machine, which is mostly used for making sand.
Applied materials
Rock, gravel, different kinds of ore, fireclay, slag and other hard materials.

Features
- Continuous rotation of the operated cone body and high productivity.
- Easy to press, impact and crush and low power consumption.
- Even particle size of products and uniformly surface wear of movable cone.
- Simple structure: frame, horizontal axis, movable cone, balance wheel, eccentric bushing, upper crushing wall (fixed cone), down crushing wall (movable cone), fluid coupling, lubrication system, hydraulic system, control system, etc.
- The movable cone swings close to discharge opening of crushing cavity, which intersects an equal parallel strip between them to make end products granularity. The feed opening is not large, which can deal with the primary crushed materials.
- This kind of cone crusher adopts dry oil and water sealing avoiding dust entering and keeping clean.
Technical Parameter
Model | Shell Specifications (mm) | Shell rotation speed (r/min) | Feeding size (mm) | Discharging size (mm) | Processing capacity (t/h) | Power (kw) | Total weight (t) | |
Diameter | Length | |||||||
MBS0918 | 900 | 1800 | 36-38 | ≤25 | 0.833-0.147 | 0.62-3.2 | 18.5 | 5.9 |
MBS0924 | 900 | 2400 | 36 | ≤25 | 0.833-0.147 | 0.81-4.3 | 22 | 6.7 |
MBS1224 | 1200 | 2400 | 36 | ≤25 | 0.833-0.147 | 1.1-4.9 | 30 | 13.9 |
MBS1530 | 1500 | 3000 | 29.7 | ≤25 | 0.833-0.147 | 2.4-7.5 | 75 | 19.8 |
MBS1830 | 1830 | 3000 | 25.4 | ≤25 | 0.833-0.147 | 4.8-11.6 | 130 | 34.9 |
MBS2130 | 2100 | 3000 | 23.7 | ≤25 | 0.833-0.147 | 14-35 | 155 | 46.5 |
MBS2136 | 2100 | 3600 | 23.7 | ≤25 | 0.833-0.147 | 19-43 | 180 | 48.7 |
MBS2430 | 2400 | 3000 | 21 | ≤50 | 0.833-0.147 | 25-65 | 245 | 59.7 |
MBS2736 | 2700 | 3600 | 20.7 | ≤50 | 0.833-0.147 | 32-86 | 380 | 92.5 |
MBS2740 | 2700 | 4000 | 20.7 | ≤50 | 0.833-0.147 | 32-92 | 400 | 95 |
MBS3245 | 3200 | 4500 | 18 | ≤50 | 0.833-0.147 | 64-180 | 630 | 149 |
