Product Introduction
Trommel washing machine is a special screening equipment developed by our company for power plants, coking plants, building materials, metallurgy, chemical industry, mining, and other industries. It has the advantages of simple and reliable structure, stable operation, good sealing, no pollution, low noise, quick screen change, fine classification, large sorting ratio, high output, accurate sorting, low failure rate, and convenient maintenance.
Applied materials
Ore, coal, sand, gravel, chemical, soil, coke, white ash, compound fertilizer, topsoil, etc.

Features
- Huge Productivity.
- Woven mesh or heavy-duty punch plates panels can be fitted to the drum to meet all application requirements.
- Excellent Serviceability & Economy.
Technical Parameter
Model | Specification (mm) | Stone Screening Capacity (t/h) | Sand Screening Capacity (t/h) | Motor Power (kw) | Reducer | Gross Weight (t) |
---|---|---|---|---|---|---|
TSGT-1240 | 1200×4000 | 60 | 50 | 5.5-7.5 | 400 | 4.5 |
TSGT-1540 | 1500×4000 | 120 | 80 | 11-15 | 400 | 5.8 |
TSGT-1840 | 1800×4000 | 150 | 120 | 15-18 | 500 | 7 |
TSGT-2040 | 2000×4000 | 200 | 150 | 18-22 | 650 | 10 |
TSGT-2240 | 2200×4000 | 230 | 160 | 18-22 | 650 | 13 |
TSGT-2640 | 2600×4000 | 260 | 180 | 37 | 750 | 15 |
